PE (polyethylene) is one of the most basic plastic. Due to its high strength, high temperature resistant, anti-corrosion, non-toxic, wear resistance and other characteristics, PE material is widely used in water supply and drainage manufacturing. According to the wall thickness, it can be divided into SDR11 and SDR17.6 series. Compared with steel pipe, PE pipe construction process is simpler and has certain flexibility. More importantly, it will save a lot of processes by leaving out the antiseptic treatment.
Return| specifications | D | d | I | D1 | d1 | l1 | H | A/box |
| Φ75x40 | 75 | 60.8 | 71.5 | 40.4 | 29.5 | 48 | 152 | |
| Φ75x50 | 75 | 60.8 | 78.5 | 50.8 | 40.4 | 55 | 146.5 | |
| Φ75x63 | 75 | 60.8 | 77 | 63 | 50 | 55 | 144.6 | |
| Φ90x50 | 90 | 73.6 | 79 | 50 | 39 | 59 | 173 | 60 |
| Φ90x63 | 90 | 73.6 | 79 | 63 | 76 | 63 | 169 | 60 |
| Φ90x75 | 90 | 73.6 | 79 | 75 | 61.4 | 70 | 164 | 50 |
| Φ110x50 | 110 | 90 | 82.5 | 50.8 | 38.7 | 54.5 | 194.5 | |
| Φ110x63 | 110 | 90 | 82 | 63 | 76 | 63 | 191 | 48 |
| Φ110x75 | 110 | 90 | 101 | 76 | 60.5 | 80 | 200 | |
| Φ110x90 | 110 | 90 | 82 | 90 | 73.6 | 79 | 180 | 38 |
| Φ160x75 | 160 | 129 | 98 | 75 | 60 | 70 | 253 | |
| Φ160x90 | 160 | 130.8 | 98 | 90 | 73.6 | 79 | 245 | 38 |
| Φ160x110 | 160 | 130.8 | 98 | 110 | 90 | 82 | 228 | 18 |
| Φ200x90 | 201 | 161 | 125 | 90 | 69 | 88 | 271 | |
| Φ200x110 | 200 | 163.6 | 112 | 110 | 90 | 82 | 264 | 6 |
| Φ200x160 | 200 | 163.6 | 112 | 160 | 130.8 | 98 | 249 | 6 |
| 以下規(guī)格需預(yù)定 | 元/個(gè) |
Φ75x32 Φ90x32 | 18.50 |
Φ250x225 Φ315x160 Φ315x200 Φ315x250 Φ355x315 Φ400x160 Φ400x200 Φ400x250 Φ400x315 Φ400x355 Φ450x200 Φ450x250 Φ450x315 Φ450x400 Φ500x450 Φ560x500 Φ630x560 | 341.78 470.00 499.10 482.90 746.76 761.46 782.04 804.09 859.95 879.06 898.17 936.39 992.25 1045.17 3391.29 3679.41 3858.75 |
